BPC-3064

Model

BPC-3064-1A1

BPC-3064-2A1

Processor System

CPU

Intel® Celeron® J6412 Processor

Frequency

up to 2.60GHz

BIOS

UEFI

Memory

Technology

Dual Channel DDR4 3200MHz

Max. Capacity

32GB

Type

2 x 260-pin SO-DIMM

Display

Graphics Engine

Intel® UHD Graphics

Multiple Display

2

HDMI

2 x HDMI, Max Resolution 4096 x 2160

1 x HDMI, Max Resolution 4096 x 2160

VGA

N/A

1 x VGA, Max Resolution 1920 x 1200

I/O Interface

 USB

4 x USB3.2 (Gen1), 2 x USB2.0

2 x USB3.2 (Gen1), 4 x USB2.0

Serial Port

2 x RS-232/422/485, 2 x RS-232

Ethernet

2 x GbE (Intel® i210-AT)

2 x 2.5GbE (Intel® i226-V)

Audio

1 x Line-out

N/A

Antenna Hole

2

Storage

2.5” SSD

1 x 2.5” SATA SSD

 M.2

1 x M.2 M-Key 2280 (PCIe x2 and SATA III)

Expansion

M.2

N/A

1 x M.2 B Key 3042/3052 (PCIe x1,

USB3.2w/ SIM slot for 4G/5G module)

Mini PCIe

1 x Full-Size Mini-PCIe (PCIe x1, USB2.0 w/

SIM slot for 4G/5G module)

1 x Full-Size Mini-PCIe (PCIe x1, USB 2.0 for

WIFI/BT module)

SIM Holder

1 x Nano-SIM Holder

Power

Power Mode

AT/ATX

Power Supply Voltage

12~36V DC Input

9~24V DC Input

Power Connector Type

1 x DC Power Connector, 1 x 2-pin Terminal Block

Mounting

Type

Wall Mount

Environment

Operating Temperature

-20C ~ 60°C

Storage Temperature

-40 ~ 80°C

Humidity

0% ~ 90% (non-condensing)

General

Vibration

IEC 60068-2-64: 5Grms, random, 5~500 Hz, 1hr/axis

Shock

IEC 60068-2-27: 50G, half-sine, 11ms duration

Certification

CE/FCC Class A

Thermal Dissipation

Fanless System

Material

Aluminum & SECC

Dimensions (W x D x H)

238 x 155 x 55mm

Net Weight

1.8kg

Operating System

Windows 10 IoT, Windows 11 (IoT/Professional), Linux
