MEGA-3110

MEGA-3110
High-Performance GPU Computer with Intel® 8th / 9th LGA1151 Processor
  • Quote

  • Datasheet

特點
list_dot_01.pngSupports 8th / 9th Intel® Core™-i LGA 1151 Processors
list_dot_01.pngTriple Display Supported by VGA, DVI and Display Port
list_dot_01.pngDual DDR4 2400 MHz SO-DIMM up to 32 GB
list_dot_01.png3 x Intel GbE Ports, Support Wake-on-LAN and PXE
list_dot_01.png2 x Removable 2.5“ SATA HDD Bays and
   2 x Internal 2.5” SATA HDD Bays
   Supporting RAID 0, 1, 5, 10
list_dot_01.png-40 ~ 70°C Operating Temperature
list_dot_01.png2 x CFast / mSATA Sockets
應用
list_dot_01.pngEdge Computing
list_dot_01.pngTraffic Vision
list_dot_01.pngIntelligent Control
list_dot_01.pngDeep Learning
list_dot_01.pngArtificial Intelligence
list_dot_01.pngVoice Recognition
Model MEGA-3112 MEGA-3113
Processor System CPU Support 8th/ 9th Intel® Core™ i3 / i5 / i7 Desktop35W/65W LGA 1151 Processors
System Chipset Intel® Q370 Express Chipset
BIOS AMI B IOS, 256Mbit SPI Flash ROM On Board
Memory Technology Dual Channel DDR4 SO-DIMM Sockets
Max. Capacity 32 GB
Socket 2 DDR4 260-pin SO-DIMM
Display Graphics Engine Integrated Intel® UHD Graphics 630
VGA 1 x VGA (1920x1080)
DVI-D 1 x DVI-D (1920 x 1200)
HDMI N/A
Display Port
1 x DP (3840x2160)
Multi Display
Yes
I/O Interface USB 6 x USB 3.2
Serial

6 x COM (RS-232/422/485), with Auto Flow Control, DB9

GPIO 8 x Isolated DI and 8 x Isolated DO (2x9-Pin Terminal Block)
Ethernet
3 x GbE RJ45,
GbE1: Intel® i219-LM(Support Wake-on-LAN and PXE)
GbE2~GbE3: Intel® i210-AT GbE (Support Wake-on-LAN and PXE)
Audio
Lin out, Mic in
CMOS Battery
1 x Removable CMOS Battery, 1x External Clear CMOS Switch
Expansion
miniPCIe/ M.2 Slot
2 x Full-size Mini-PCIe Socket(mux with mSATA), 2x Full-size Mini-PCIe
SIM socket
2 x External SIM Socket
Antenna Hole
8 x Antenna Hole
PCI/ PCIe Slot
1 x PCIe X16 slot, 1x PCIe X8 slot (4-Lane)
1x PCIe X16 slot, 2x PCIe X 8 slot (4-Lane)
Storage
HDD/SSD 4 x SATA HDD bay (2x Removable 2.5" SATA HDD Bay, 2x Internal 2.5" SATA HDD Bay)
RAID
RAID 0, 1, 5, 10
CFast Socket
2 x CFast Socket (Shared by 2x mSATA)
mSATA/M.2 2 x mSATA Socket (Shared by 2x Mini-PCIe and 2x CFast)
Power
Power On Model AT/ATX
Power Supply Voltage power supply1: 9~48VDC;power supply2:9~24V (support power ignition)
Power Connector Type
2 x 3-pin Terminal Block Connector with Power Input
Power Consumption (Max.) 21A @ 24 V (500W), with 2080Ti graphic card 42 A @ 24 V (1008W), with 3090 graphic card
Battery CR2032; 3.3V
Power Connector Type AT / ATX (Support Hardware AT, ATX Power Mode)
Protection
Over Voltage Protection (OVP) Up to 52V
Reverse Voltage Protection (RVP) up to -48V
Over Current Protection (OCP) 20A
Car Mode 1 x PC/Car Mode Switch
Mounting Type Wall mounting/Stand mounting
Environment
Operating Temperature -40~70° C (-40~158° F) without GPU Card; -40~60° C (-40~140° F) with GPU Card
Storage Temperature -40~85° C (-40~185° F)
Humidity 5~95% @ 40° C, non-condensing
Vibration
3 Grms, 5-500 Hz, 3 Axis
Shock
30 Grms, Half-sine 11 ms
General Certification CE/FCC
Thermal Dissipation Fan based System
Material
Extruded Aluminum with Heavy Duty Metal
Dimensions (W x H x D)
148 x 241.5 x 356 mm (5.83” x 9.51” x 14.02”)
168 x 241.5 x 356 mm (6.61” x 9.51” x 14.02”)
Net Weight 7.35kg (16.20lb) 7.55kg (16.64 lb)
Operating System Windows 10 (IoT / Professional), Linux


Packing List

Description
1 x MEGA-3110 Series Machine
Ordering Information

Part No. Description
MEGA-3112 Intel® 8th / 9th Core™ i3 / i5 / i7 GPU Computer with 1VGA, 1DVI-D, 1 DP, 3x GbE RJ45, 6x USB 3.2, 6x RS232/422/485, 1 DIO, Line out, Mic in, 2x CFast/mSATA, 2x Removable 2.5”SATA HDD Bay, 2x Internal 2.5” SATA HDD Bay, 1x PCIeX8 Slot (4-lane) and 1x PCIeX16 Slot
MEGA-3113 Intel® 9th/8th Core™ i3 / i5 / i7 GPU Computer with 1VGA, 1DVI-D, 1 DP, 3x GbE RJ45, 6x USB 3.2, 6x RS232/422/485, 3x GbE RJ45, 6x USB 3.2, 6x RS232/422/485,1 DIO, Line out, Mic in, 2x CFast/mSATA, 2x Removable 2.5” SATA HDD Bay, 2x Internal 2.5” SATA HDD Bay, 2x PCIeX8 Slot (4-lane)and 1x PCIeX16 Slot
Optional Items

Part No.
Description
AWD-4G003
4G(LTE) EG25-G+ 2 antenna, Full size (for global)
AWD-WF001
Wi-Fi 802.11 bgn (1T1R) +1 Antenna (Single band), Half-size mini PCIe
AWD-WF003
Wifi 802.11 a/b/g/n/ac/BT4.0 (2T2R)+ 2 Antenna(Dual band), Half size mini PCIe
i7-9700TE
Intel® Core™ i7-9700TE (8-Cores, up to 3.8 GHz, 35W TDP)
i5-9500TE
Intel® Core™ i5-9500TE (6-Cores, up to 3.6 GHz, 35W TDP)
i7-8700T
Intel® Core™ i7-8700T (6-Cores ,up to 4.0 GHz, 35W TDP)
i5-8500T
Intel® Core™ i5-8500T (6-Cores, up to 3.5 GHz, 35W TDP)
i3-8100T
Intel® Core™ i3-8100T (4-Cores, up to 3.1 GHz, 35W TDP)
AWD-kit2USB30
mini PCIe to 2 USB3.0
AWD-kit2LAN
mini PCIe to 2 LAN
AWD-kit2COM
mini PCIe to 2 COM RS 422/485
55400-0000-M5
Power Supply 24V/ 21A 500W with 4x DC Cable, Phoenix Connector
55400-0001-M5 Power Supply 48V/ 21A 1000W with 4x DC Cable, Phoenix Connector
30130-0000-CA
Power Cord,3-pin US Type SL-2 + Y,180cm
30131-0000-CA Power Cord,European Type SL-6 + Y,180cm
